Desmontaje de una PlayStation 3

Escrito Por: Mint137
Publicado: 24/10/09
  • Comentarios: 47

Desmontaje de una PlayStation 3

Publicado: 24/10/09

Desmontaje

Introducción

Esto es un desmontaje del lanzamiento original de la PlayStation 3. Una de las mejores unidades que tenía retrocompatibilidad y los lectores de tarjeta. Por desgracia esta unidad tiene la GPU dañada, así que está rota.

Editado: Apodo fix, formalmente Karasumachitose. Disculpas por cualquier inconveniente que esto pueda causar.

  1. EOENtGXoU2QgHXpt
    EOENtGXoU2QgHXpt
    aXDPvVg5wEMdEcEv
    BdlGEXaWkbrpS6b2

    • Aquí está, una de los dos modelos originales de PS3 disponibles en su lanzamiento (60GB).º

    • Tiene retrocompatibilidad con la PS1/PS2 y un lector de multitarjetas. La actual PS3 Slim no tiene lector de tarjetas. El otro modelo de lanzamiento le faltaba el lector de tarjetas y el Wi-Fi (20GB).

    I turn it On and it just automatically shuts off ok Google

    Timothy Thompson -

  2. RD55tPWx1S5O6CON
    RD55tPWx1S5O6CON
    P25CLedeEGemBaS2

    • ¡Vamos a empezar!

    • Quita la tapa de acceso al disco duro de la parte inferior de la PS3.

  3. hMpKNjRovhvWMM32

    • Utiliza un destornillador Phillips #1 para quitar el tornillo azul.

  4. apfRIwqmACwvGIaQ
    apfRIwqmACwvGIaQ
    XKn5cEyvi2h4kYYv
    ycWZ2Ak66ZjDploV

    • Levanta la palanca metálica.

    • Desliza el disco duro hacia la parte frontal de la carcasa.

    • Tira de el y sácalo de la unidad.

    • Esto es todo lo necesario para acceder al disco duro de tu PS3.

  5. 4P4PhtHMFVYHemPR
    4P4PhtHMFVYHemPR
    TUWSaE1oMTlk2wuQ
    bmBakcNYepHsjbiD

    • Quita la pegatina de la garantía.

    • Evidentemente esto te hará perder la garantía. Estás avisado.

    • Utiliza tus uñas y haz palanca para quitar el pie de goma de debajo de la pegatina.

  6. BOEq4WTlrqbhYZkd
    BOEq4WTlrqbhYZkd
    M3tmpnZGOwcmFRLg

    • Utiliza el destornillador TOR (T8 o T10) para quitar el tornillo torx que está debajo del pie de goma.

    • Este tornillo tiene un "pincho" en la punta, pero la mayoría de destornilladores torx son capaces de desatornillarlo.

    Mine was a T10

    Zach Tharp -

    this screw came out using a phillips #1or#2 with no issue.

    turtlefresh -

    A 1/8 flathead screwdriver fit perfectly for me on this screw.

    Nathan H -

  7. o4De4stcAirQEbpG
    o4De4stcAirQEbpG
    SYSTcHmZj3XEGiAE
    mbFYZOO5AjYAWRON

    • Coloca tu PlayStation 3 boca arriba de forma que seas capaz de leer el logo de "PlayStation 3"

    • Coloca la palma de tu mano en el logo de PlayStation 3 y desliza la carcasa de plástico frontal hacia a ti para quitarla del resto de la carcasa. Colócala a un lado.

    How Do you open

    dantdm numor -

    My case is still stuck, and refusing to budge… I removed the screw and HDD already.

    Logan Stevens -

  8. Ev4dob1mIjEURXwS
    Ev4dob1mIjEURXwS
    bPhd5DjWaHqdhCdZ
    UJXgF1kAFYOyWY5S

    • Quita el receptor metálico que soporta el tornillo torx que acabas de desatornillar.

    Some PlayStation3 gen 1 consoles do not have a removable receiver. If yours does not, just skip this step.

    Joshua Law -

    No people. Ignore that last guy. Stick to your guns and hold your ground. Even if your specific console does not HAVE the removable receiver, remove it anyways. :|

    Freaking GENIUSES up in here.

    Gary Hall -

  9. v4GKPBoofFUjtRPu

    • Quita los 9 tornillos de la carcasa exterior utilizando un destornillador Phillips #2.

    • 6 tornillos largos.

    • 1 tornillo mediano.

    • 2 tornillos pequeños.

    The annotation on the photo in Step 9 is inaccurate. The blue circle should be aqua/cyan coloured, while the two cyan/aqua coloured circles should be blue. No biggie, great disassembly otherwise.

    paulius -

    Cita de paulius:

    The annotation on the photo in Step 9 is inaccurate. The blue circle should be aqua/cyan coloured, while the two cyan/aqua coloured circles should be blue. No biggie, great disassembly otherwise.

    I double checked it, it should be correct. There is only one medium screw and two small screws.

    Mint137 -

    If you leave the two small screws until after you remove the top (they aren't attached) it will make things easier because the card readers will stay down and there will be no ribbon cable to deal with when removing the top.

    Julian Turner -

    I have found the same. It can be a mess otherwise.

    Joshua Law -

  10. mqJ3BjSCI26SFtQQ
    mqJ3BjSCI26SFtQQ
    IrvshiQRsu2JURNu
    HM2hVeBGwKOKxSTI

    • LEE ESTO ANTES DE REALIZAR EL SIGUIENTE PASO Y DEL PROCEDIMIENTO. Localiza las dos pestañas en la parte trasera de la PS3, presiónalas al mismo tiempo y levanta la carcasa exterior para quitarla de la placa principal PERO, ten cuidado ya que hay un cable plano conectando la carcasa a otro hardware.

    • Los cables planos son muy frágiles. Ten cuidado cuando los quites o los conectes.

  11. TK3MVfDX4LP6NMDf
    TK3MVfDX4LP6NMDf
    rUJFxxyVwI52cKg2
    edyrSSPXIFjQtXGk

    • Desconecta el cable plano y coloca la carcasa a un lado.

    • Si quieres quitar el lector plástico de tarjetas, localiza las dos pestañas que lo mantienen sujeto a la carcasa, separa las pestañas y levanta el lector de tarjetas para quitarlo de la carcasa.

  12. prPfJoOuyNaBZrdC
    prPfJoOuyNaBZrdC
    eqkkLQVMqRwfUd6v
    LHhsUhXPMXTcCFM5

    • Localiza las dos pestañas que lo mantienen sujeto a la carcasa, separa las pestañas y levanta el lector de tarjetas para quitarlo de la carcasa.

  13. nXYXbRfebgrj2CSM
    nXYXbRfebgrj2CSM
    xcQMiFj32w1IZYiT
    prwrIKlcMFdCc3BT

    • Ahora, en la unidad principal, levanta y desconecta el cable negro de radiofrecuencia (RF) del conjunto inalámbrico, realiza esto utilizando una espátula.

  14. Nhu3daPC1woXUl16
    Nhu3daPC1woXUl16
    gohG3WgOmvL6YdKm

    • Quita el cable plano del conjunto inalámbrico.

  15. 2rGabImeYGQatpWH

    • Quita los cuatro tornillos Phillips #2 de la parte superior del conjunto inalámbrico.

  16. 2nCCdfqyGCNNk1GH
    2nCCdfqyGCNNk1GH
    ZBsBD2f5PyD5rsBs
    Qm1VEC4EUnh2gkjl

    • Levanta el conjunto inalámbrico de la placa base y colócalo a un lado.

    • Desconecta el cable plano de la placa base y colócalo con el conjunto inalámbrico.

  17. lvZQCiOR6FqdqKOd
    lvZQCiOR6FqdqKOd
    1lcsiXgM4ZIuoX4v
    Ud3ERWVLRQtujyxT

    • Localiza el otro conjunto inalámbrico al cuál está conectado el cable RF negro.

    • Quita el tornillo Phillips #2 que lo mantiene asegurado a la placa base, levanta el conjunto y ponlo a un lado.

    The black wire is taped in, so make sure you do not use force if it’s not coming out.

    N7 RiZe -

  18. rSx2VdTNtTSdCtHi
    rSx2VdTNtTSdCtHi
    4R51mVGBOMVxwsHd

    • Quita los cables que conectan la fuente de alimentación a la placa base.

    • Quita el conector AC de la fuente de alimentación.

    Power connector on my 20gig launch unit was epoxied. If this is the case with yours be VERY careful. Mine popped off the board, now searching for a fix.

    Ryan Burns -

  19. QHgdlHbDbgc3VBRw
    QHgdlHbDbgc3VBRw
    rvhZAPZfRFJVnEk3
    sycwrEJcUO1XWlZO

    • Quita los cinco tornillos Phillips #2 de la fuente de alimentación, y saca la fuente de alimentación hacia arriba y fuera del cuerpo cuerpo principal. Coloca todo a un lado.

    • Mientras quitas la fuente de alimentación, hay 2 pines de conexión que la conectan a la placa base.

  20. XeC12QPGRFKDYsEU
    XeC12QPGRFKDYsEU
    hZoEcGj3j11fvL1u

    • Los tornillos que sujetan la unidad Blu-ray a la placa base los has quitado en un paso anterior.

    • Desconecta el conector de alimentación (de color gris) que se encuentra al lado de la unidad.

  21. ARsNXaWsPN4aSyDB
    ARsNXaWsPN4aSyDB
    VXyPKSlrH2BiYMSa

    • LEE ESTE PASO COMPLETO ANTES DE CONTINUAR. Levanta el lector lentamente para poder ver el cable plano que hay debajo.

    • Quita ese cable plano de la placa base y coloca la unidad con el cable a un lado.

    Remove the ribbon cable from the drive end, not the motherboard end. The clip holding the ribbon cable to the motherboard is difficult to reattach and will often snap. It does make it a bit more difficult to disassemble but far safer.

    Root Ginger -

    I had to use two spudgers to pry the clip UP on the motherboard to release the cable.

    Andrew Hathaway -

    If you do break the clip on the motherboard side, just clip the ends off the broken clip and, using the thin side, push it in the remaining motherboard recess so it keeps the ribbon connection in place. There are multiple youtube vids if you need additional info. Had to do mine and worked like a charm.

    lemoyce78 -

  22. 2lkGlWIlOYDmNOI6
    2lkGlWIlOYDmNOI6
    SOaBscig6jOPgTUG

    • Quita el cable plano que sujeta la placa del botón de on/off y de sacar el disco (eject) a la placa base.

    This just broke my PS3 permanently.

    TheTank20 -

  23. SuaefOpFUwKWBDSZ
    SuaefOpFUwKWBDSZ
    GWy2TOF1kbGa6coy
    OlsjKXMXPrrONrvn

    • Quita los 4 tornillos Phillips #2 que sujetan el circuito a la carcasa.

    • Quita el circuito de la carcasa.

    • Estos tornillos son de tamaño mediano, diferentes del resto de tornillos Phillips #2.

  24. TWpAIE2NnMDtGDBo
    TWpAIE2NnMDtGDBo
    u13LsMuwntOlXjVu

    • Quita los 9 tornillos del cuerpo principal.

    • 5 tornillos Phillips #2 medianos.

    • 2 tornillos Phillips #1 pequeños.

    • 1 tornillo Phillips # con arandela de toma de tierra.

    • 1 tornillo tipo perno (debajo del cable de la corriente alterna "AC").

    There seems to be a significant flaw in the design here where a screw can damage the USB port power traces on the motherboard. For some reason they ran the traces right under the screw holes. Should there not be nothing there (better situation would be a hole).

    Temi B -

    What does the bolt philips screw look like?

    mglmoncraft -

  25. fhOZeMVcnBO4WjKR
    fhOZeMVcnBO4WjKR
    553Gn4h2IGbGwyLu

    • Coge la placa base desde las zonas que se muestran en la imagen y levántala para quitarla de la carcasa.

    • Deja la carcasa negra a un lado.

  26. Fjn1WdDVDYBIrSUV
    Fjn1WdDVDYBIrSUV
    rAV3RlLZxuGHJCik
    yu14EQSrMyidJfG4

    • En el cuerpo principal, localiza las 5 pestañas de bloqueo de plástico que sujetan el protector de E / S de plástico trasero al cuerpo principal.

    • Haz palanca en las pestañas para quitarlas del plástico trasero.

  27. vcMQACRS1x2IXDWn
    vcMQACRS1x2IXDWn
    1JSVmie4uJikbwJr
    qwlmBKbwulYlqkqT

    • Quita el conector de alimentación del ventilador.

  28. nMmnpRVXCGE6CRWS
    nMmnpRVXCGE6CRWS
    oH4Rx34G4LWy2vLn
    WCPCxXdHcqIshhNR

    • Quita los 3 tornillos Phillips #2 que mantienen el ventilador sujeto al cuerpo principal.

    • Estos son tornillos muy pequeños.

    • Levanta el ventilador hacia arriba y quítalo del cuerpo.

    • ¡Mira el tamaño de esta cosa!

  29. PdpDpVLXJZXIYVAf
    PdpDpVLXJZXIYVAf
    FPlIAhPwV3lwfba6
    ZTVFVWCjA4qEBOja

    • En la parte superior de la placa base, quita también los tornillos Phillips #2 que sujetan el disipador.

    • Quitarlos también reduce también la presión en la GPU y la CPU.

    • Quita las placas y los tornillos de la placa base.

    I broke off one of these screws, 'Philips #2 screw' has not gotten me a correct screw from google.

    Any clue what exact screw this would be?

    PS

    I have an idea how I could remove the broken screw, but any suggestions?

    R zaiD -

    Search on Ebay under PS3 Screw there are some on there with clamps.

    Root Ginger -

  30. FAOWv4Xd34eVDYwl
    FAOWv4Xd34eVDYwl
    4mfV65FaAGeZk5Xn
    OqRsROZBK6UPIJ4h

    • Dale la vuelta a la placa base.

    • Levanta (o haz palanca con los dedos) el disipador para quitarlo de la placa base y de los procesadores.

    • Vas a necesitar hacer un poco de fuerza ya que la pasta térmica se queda un poco pegada al disipador y a los procrsadores.

    • Nota: Si tienes lista la nueva pasta térmica, limpia la pasta vieja bien y aplica la nueva cuando vuelvas a lontar todo. En caso de que no vayas a cambiarla no toques la pasta vieja.

    Looks to me if your goal is to replace the thermal paste, this is as far as you need to go. Apply the new paste and begin reassembly. Here's a video showing how to apply the paste: http://www.youtube.com/watch?v=EyXLu1Ms-...

    objbuilder -

    Wich is the best way to apply the paste and what brand do you reccomend?

    roblyons39 -

    Just use a small dot, not bigger than a pea right in the middle. Let the heatsink spread it out.

    Randy Laird -

    DO NOT DO THIS IF YOU DO HAVE THERMAL PASTE!!!

    If the thermal paste is disturbed you MUST remove all the old paste and apply new (unless you are okay with destroying your processors). To remove the old paste, cotton swabs work best. Once you have removed as much as you can, dampen a cotton swab with rubbing alcohol and carefully clean the processor surface AND the heat sink surface using small circular motions, being careful to not allow any alcohol to contact the main board. Do this until ALL traces of the old compound are COMPLETELY removed. Once removed, allow a short amount of time for the alcohol to completely evaporate. Once the alcohol is evaporated, place a SMALL amount of new compound (I use Arctic Silver) directly onto the processor (about the size of a pea OR LESS). Using a straight edge (such as a credit or ID card) carefully spread the compound into an even, thin layer which completely covers the surface of the processor.

    Gary Hall -

    This is not as hard as it sounds. Just take your time and get it as even as you can. And gaps in the paste will result in “hot spots”, which can easily damage your processor (this is why just “letting the heat sink spread it out” is such a bad idea). The layer should only be about 1/64” (0.016”) to 1/32” (0.031”) thick. For reference, a common sheet of paper is about 0.004” thick, so roughly 4 to 8 sheets of paper thick. Do remember that this is NOT as critical as I am making it out to be. It is simply a reference for “a thin layer of compound”. Don’t overthink it.

    Gary Hall -

    Now that your fresh compound has been applied, reinstall the CLEAN heat sink as evenly and gently as possible. Install the fasteners and tighten, tightening and alternating n SMALL INCREMENTS. The idea here is to tighten the heat sink in as even a fashion as possible. This helps to ensure the most even distribution of thermal compound as possible.

    I have repaired many Xbox 360s and PS3s in my time, and have never had this method fail, and as en electrical engineer would encourage anyone to follow these procedures when replacing any thermal compounds.

    Gary Hall -

  31. ClZHTwrZZeAWC6Pf
    ClZHTwrZZeAWC6Pf
    clDZfmds1Os6Oakg

    • Quita los 2 tornillos Phillips #0 del hueco del disco duro.

  32. uUA24xWVpMfqBwg2
    uUA24xWVpMfqBwg2
    Pft6bG3WO1Vsom4f

    • Para exponer la placa base, quita la batería del reloj de la placa base.

  33. rLD1EcyaSPp3Jfbx
    rLD1EcyaSPp3Jfbx
    PrONOk5EEpxRYukl
    pmtH2aTDtEDIepMn

    • Utilizando una espátula y con cuidado haz palanca en la carcasa protectora metálica que está encima de la placa base para quitarla.

  34. bQJurYHRiXEYnIjb
    bQJurYHRiXEYnIjb
    BJrxybwokNSXnW1B
    sYSAuWbCl6HZhSoy

    • Dale la vuelta a la placa base y quita la protección metálica que está en el lado contrario. Haz palanca con una espátula o con tus dedos.

  35. ErNJ5L4UPidBAARV
    ErNJ5L4UPidBAARV
    iuJktFiXXC5pHlgN

    • .Observa todos los chips con almohadilla térmica que hay en esta cosa.

    • Ahí está el chip de Emotion Engine y el de sintetización gráfica que permiten la retrocompatibilidad.

    • Procesador cell IBM. Esta CPU tiene 9 núcleos y 10 hilos y trabaja a 3.2 GHz.

    i have a SERIOUS PROBLEM. i put my ribbon cable from my bluray drive into my ps3 while it was on and i heard a pop. the drive was no loner able to recieve power and i saw someone else had the same problem but on a differnt ps3. they said it was the ic chip on the daughter board and i dont even know where that is.... im only 16 and i plan on being an electronic engineer can anyone please help me because im a SEMI-noob future genius noob now.

    Isaac King -

    Advice- Next time make sure the system does NOT have power.

    aarongeister -

  36. 4bArcZYRSFFtZKuC
    4bArcZYRSFFtZKuC
    hWNDGQCos1UoEACD
    jLwADKiJY3sDyS51

    • ¡Más chips!

    • CPU IBM cell.

    • GPU Nvidia RSX.

    How do I remove the RSX chip so I can see if it's the issue

    David Staffen -

  37. eALK2uHL5Vfo4tHN
    eALK2uHL5Vfo4tHN
    QmvtDjEVF3KIkiHX

    • Considera tu PA3 desmontada.

Autor

Mint137

Miembro Desde 24/10/09

3997 Reputación

16 comentarios

ii got a broken ps3 from my step dad, it turns on but theres no picture. I've taken it apart 3 times now and couldnt figure out how to get it fully apart. I've put everything back together and it does the same thing. So i didnt mess it up and more than it was. lol. From what i was told it was on top of a tv and a dog caught the cord and pulled it down. It slammed down on the back of the system and hasnt been able to show video and sound. Like i've said, i've tryed to mess with it but i know nothing about this stuff. Any ideas as to what could be broken? The port itself is cracked, but i've tryed HDMI and that doesnt work either. Any advice is helpful. Thank you.

shujinflik -

lol couple years later, no all u have to do is switch out the fan inside your ps3 :) it happen to mine or buy a new ps3 and switch hard drives :)

Mikegart victoria -

It's the GPU

Kajus Slekys -

I love the way you post a warning as to how fragile the ribbon cable is and then say, "remove ribbon cable" without any detail as to how to release it. Thanks. Now my PS3 is trash.

sonofjay817 -

Instructions not clear enough. Stuck my finger in a light socket.

10/10, would electrocute self again.

Randy Laird -

watch ifixit's video on youtube, it helps a lot, these pictures help out more after you see the video...

David Stevens -

Help! How to recover photos from a dead ps3?

Lin Brown -

Hello,

I'm wondering why SIXAXIS Gyroskope might stopped from working after reaseambly.

Can you please suggest something?

Alexander

ilychev -

Take the HDD out and get a new one or check what's the problem

Kajus Slekys -

Can you fix it again after splitting it? Bc. My Ps can't turn on, only in 1 second and then it turns it self off. So i told it too my dad, and he said "can you get in to the computer itself, without breaking it and then fix it again, after that" and i aswered "i don't know, i'll go chek" and here i am, knowing how to split it but not fixing it again. Uhh so please answer me... Can it be fixed again after splitting it??!

Lucas -

Great teardown tutorial. Can confirm it saved my butt when I needed to open a 60GB CECHA01 PS3, which I successfully did in addition to (a) replacing the thermal paste, and (b) clean all the dust off.

Only problem with this tutorial is what sonofjay817 mentioned: poor instruction regarding the ribbon cables. THIS IS VERY IMPORTANT: the receptor end for the Blu-Ray ribbon cable needs to have a small black tab pulled open BEFORE removing, and BEFORE inserting the cable. I accidentally got it open by chance, but you might not be so lucky without my warning - and if the ribbon cable is done for, you will need to replace it completely.

Paulo -

I followed this tare down tutorial to clean my PS3s and replace the thermal paste on my two 60gb models, afterwards both now YLOD on me. I wish there was something for re assembling everything because following the instructions backwards obviously hasn’t worked for me (both were perfectly working since new before this).

N7 RiZe -

My PS3 one's I turn it on it always go back off and I continue turning it on it keeps on for about some minutes then finally it comes on and works perfectly … what the course of it going off

olanrewajueajayi ajayi -

What kind of PSU it is using?

Karlo Miguel Borja -

Interesting, the internals of mine looks quite different. I have 2 GIANT heatsinks not shown here, maybe they were added later due to overheating

Josh Goodrich -

@step9 the big screw sizes are:

complete length 50mm (with head)

without head 48mm

threadded part 20mm

core 2mm

core with thread ~2.9mm

Peter Kvcs Tlk -
